WOLF

The big brother to our FOX family offers the best performance for your operating theater.

Despite its inconspicuous appearance, the Wolf probably has the widest range of applications of all our lasers. From laryngology and phonosurgery to otology and rhinology. Everything is possible!

Choose the right wavelength for your area of expertise

Wolf 445nm – The all-rounder

With the Wolf 445nm you have an all-rounder seeking for its equal.

Since 2016 the Wolf 445nm laser – also known as Wolf TruBlue or “the blue” – conquers every operating room worldwide. All the advantages you are used to from a KTP laser and from a CO2 laser are combined in this device. With its specific absorption properties (behavior in tissue) the Wolf 445nm proves its skills in sensitive phonosurgical applications up to large tumor resections. Due to its small dimensions, it is possible to easily change between practice and operating room if necessary. Not bigger than a shoe box, the Wolf 445nm is a flexible all-rounder.

Ideal for:

  • Laryngology
  • Phonosurgery
  • Otology
  • Rhinology

Advantages compared to other laser systems:

  • Low energy input
  • Low penetration depth of radiation into tissue
  • Contact or non-contact application
  • Precise, selective tissue interaction
  • Small footprint

Wolf 980nm

The big brother of the FOX 980nm

In some cases power reserves are needed. With 18W the Wolf 980nm offers enough power for any challenge in surgery. If you are looking for a laser that is mainly used in rhinology, but should also used for e.g. tonsillotomy, then the Wolf 980nm is just the right laser for you.

Technical data

* on the fiber end. Please specify the desired wavelength when ordering.
Laser Diodenlaser
Display Farb-Touchscreen
Wavelength: Power * 445 nm: 10 W
980 nm: 18 W
1470 nm: 10 W
Pulse length 445 nm: 1 ms to 60 s / CW
980/1470 nm: 100 µs - 45 s / CW
Pulse pause 445 nm: 1 ms to 60 s / SP
980/1470 nm: 100 µs - 45 s / SP
Aiming beam Green 532 nm, adjustable
Fiber coupling A.R.C. Laser U.C.
Power supply 100 - 240 V~ 50 / 60 Hz
Dimensions WxDxH 24,6 x 20,3 x 10,0 cm
Weight 2,8 kg
